Redi-lock Diamond Grinding Shoes are engineered for fast, aggressive grinding and surface preparation on concrete floors.
Segment types: Double H Segments
Segment sizes: 33×13mm
Diamond grit: 6#,25#,50#,100#,120#...
Metal bond: Soft, Medium,Medium hard,hard...
When selecting diamond grinding tooling, ensure the metal bond is appropriate for the hardness of the surface.
Description
Redi-lock diamond grinding shoes are designed for Husqvarna floor grinders, providing an efficient solution for concrete floor preparation and coarse grinding of concrete and terrazzo surfaces. With multiple diamond grits and bond options available, the tools can be matched to different floor conditions and grinding requirements.
Featuring a popular TWO segment design, these diamond grinding shoes offer sharp and aggressive grinding performance for fast removal of concrete surface and efficient coarse grinding. The Redi lock quick-change system allows fast and secure tool installation, helping operators reduce tooling changeover time. Reliable silver brazing provides strong segment retention during demanding grinding applications.
Specification
| Item No. | Segment No. | Segment Types | Diamond Grit | ||
| CGRH | 2 | Double H | Coarse 35/40 | Medium 50/60 | Fine 100/120 |
Application
• Concrete grinding
• Fast material removal
• Long service life
• Stable grinding performance
Applications include:
Diamond Grinding Shoes For Concrete Floor Grinding
Surface Preparation
Concrete Polishing Preparation
To choose the right diamond floor grinding shoe and diamond grinding cup wheels from suppliers, you must know the hardness of your concrete.
Concrete can be soft, hard, abrasive, dusty and brittle, etc. There are no two floors are ever the same, typically they are more abrasive when the floor is new or have a high sharp sand content. The more abrasive the floor the harder bond you will need to get the best performance out of the diamonds.
Bond - The strength of the metal binder that holds the diamond grit in the segment. Typically the harder the bond the longer the life. Soft concrete needs the hard bond, medium-hard bond for medium concrete, and soft bond for hard concrete.
| Concrete Hardness | Recommended Metal Bond Hardness |
| Hard concrete | Soft bond |
| Medium concrete | Medium hard bond |
| Soft concrete | Hard bond |
OEM Package
Besides the neutral white box package, we have the OEM finishing package such as individual blister and paper insert for the blade. We can also make the package as your design, and provide package design service too.
Why Choose Corediam Diamond Grinding Plate?
The right grinding shoes must match the concrete hardness, machine type, and grinding purpose.
Corediam not only provides grinding products to its customers, but also diamond grinding solutions.
1. Ultra coarse diamond grit design, 6#,16#
2. Any segment types you want
3. Compatible with leading concrete grinder brands
4. OEM & Custom Diamond Grinding Shoes
5. Flexible MOQ
6. Supports sample testing
7. ISO 9001, ISO 14001 and EN 13236 international standards
Ready to upgrade your concrete grinding performance? contact Corediam for recommendations or pricing.
